Price: 1718.- EUR (Price includes 24% VAT of the Republic of Estonia, in case of sales to other countries, the VAT rate of the respective country is applied).
Make an inquiry to place an order!
AN-X ENGINE
Integrated into the Motion Control system, the AN-X Engine allows you to create expressive, unique analog sounds.
– Two filters
– 10 filter types
– Pulse width modulation
– Oscillator Self Sync
– Ring modulation
– FM, and wave shaper
– Wave folder
– Voltage drift and aging settings to simulate vintage synth behavior
AWM2
Experience realism and detail with the MODX M Advanced Wave Memory (AWM2). Offering up to 128 Elements per Part, AWM2 allows for more layers and articulations, giving you an expansive canvas for sound creation, especially for “nameable” sounds such as piano and strings.
268 NOTES TOTAL POLYPHONY
MODX M offers up to 268 notes of polyphony across its three engines:
– 128 notes for AWM2 Preset and User Waveform Parts
– 128 notes for FM-X Parts
– 12 notes for AN-X Parts
AND MORE
– PRESET WAVE AND FLASH MEMORY UPGRADE: MODX M offers approx. 2x the memory over MODX/MODX+ with an increase from 5.68 GB to 10.7 GB of AWM2 memory, and 1.9 GB of User flash memory.
– VCM ROTARY SPEAKER: The VCM Rotary Speaker effect simulates the rich and enveloping motion of a classic rotary speaker cabinet.
MODX M8 | MODX M7 | MODX M6 | ||
|---|---|---|---|---|
| Dimensions | Width | 1,310 mm (51-9/16″) | 1,089 mm (42-7/8″) | 882 mm (34-3/4″) |
| Height | 152 mm (5-15/16″) | 117 mm (4-5/8″) | 117 mm (4-5/8″) | |
| Depth | 391 mm (15-3/8″) | 347 mm (13-11/16″) | 347 mm (13-11/16″) | |
| Weight | Weight | 13.6 kg (29 lb, 15 oz) | 7.6 kg (16 lb, 12 oz) | 6.6 kg (14 lb, 9 oz) |
| Keyboard | Number of Keys | 88 | 76 | 61 |
| Type | GHS Keyboard | Semi-weighted FSB Keyboard | Semi-weighted FSB Keyboard | |
| Initial Touch | Yes | Yes | Yes | |
| Aftertouch | No | No | No | |
| Tone Generator | Motion Control Synthesis Engine AMW2: 128 Elements (max.), FM-X: 8 Operators, 88 Algorithms, AN-X: 3 Oscillators, 1 Noise | Motion Control Synthesis Engine AMW2: 128 Elements (max.), FM-X: 8 Operators, 88 Algorithms, AN-X: 3 Oscillators, 1 Noise | Motion Control Synthesis Engine AMW2: 128 Elements (max.), FM-X: 8 Operators, 88 Algorithms, AN-X: 3 Oscillators, 1 Noise | |
| Maximum Polyphony | AWM2: 128 (max.; stereo/mono waveforms), FM-X: 128 (max.), AN-X: 12 (max.) | AWM2: 128 (max.; stereo/mono waveforms), FM-X: 128 (max.), AN-X: 12 (max.) | AWM2: 128 (max.; stereo/mono waveforms), FM-X: 128 (max.), AN-X: 12 (max.) | |
| Multi Timbral Capacity | 16 Parts (internal), Audio Input Parts (A/D*1, USB*1) *1 stereo Part | 16 Parts (internal), Audio Input Parts (A/D*1, USB*1) *1 stereo Part | 16 Parts (internal), Audio Input Parts (A/D*1, USB*1) *1 stereo Part | |
| Wave | Preset: 10.7 GB (when converted to 16-bit linear format), User: 1.9 GB | Preset: 10.7 GB (when converted to 16-bit linear format), User: 1.9 GB | Preset: 10.7 GB (when converted to 16-bit linear format), User: 1.9 GB | |
| Performance | 3,427 | 3,427 | 3,427 | |
| Filter | 18 types | 18 types | 18 types | |
| Effects | Reverb x 13 types, Variation x 88 types, Insertion A x 88 types*2, Insertion B x 89 types*3, Master Effect x 26 type, *2 A/D part insertion x 83 types *3 Part 2~16: 88 type, A/D part insertion x 83 types (Preset settings for parameters of each effect type are provided as templates) Master EQ (5 bands), 1st part EQ (3 bands), 2nd part EQ (2 bands) | Reverb x 13 types, Variation x 88 types, Insertion A x 88 types*2, Insertion B x 89 types*3, Master Effect x 26 type, *2 A/D part insertion x 83 types *3 Part 2~16: 88 type, A/D part insertion x 83 types (Preset settings for parameters of each effect type are provided as templates) Master EQ (5 bands), 1st part EQ (3 bands), 2nd part EQ (2 bands) | Reverb x 13 types, Variation x 88 types, Insertion A x 88 types*2, Insertion B x 89 types*3, Master Effect x 26 type, *2 A/D part insertion x 83 types *3 Part 2~16: 88 type, A/D part insertion x 83 types (Preset settings for parameters of each effect type are provided as templates) Master EQ (5 bands), 1st part EQ (3 bands), 2nd part EQ (2 bands) | |
| Note Capacity | 1 Song/Pattern: Approx. 130,000 notes, Store area: Approx. 520,000 notes (Pattern); approx. 520,000 notes (Song) | 1 Song/Pattern: Approx. 130,000 notes, Store area: Approx. 520,000 notes (Pattern); approx. 520,000 notes (Song) | 1 Song/Pattern: Approx. 130,000 notes, Store area: Approx. 520,000 notes (Pattern); approx. 520,000 notes (Song) | |
| Note Resolution | 480 ppq (parts per quarter note) | 480 ppq (parts per quarter note) | 480 ppq (parts per quarter note) | |
| Tempo (BPM) | 5 – 300 | 5 – 300 | 5 – 300 | |
| Sequence formats | MONTAGE M/MODX M original format, SMF formats 0, 1 | MONTAGE M/MODX M original format, SMF formats 0, 1 | MONTAGE M/MODX M original format, SMF formats 0, 1 | |
| Arpeggio | Parts: 8 Parts simultaneous (max.), Preset: 10,922 types or more, User: 256 types | Parts: 8 Parts simultaneous (max.), Preset: 10,922 types or more, User: 256 types | Parts: 8 Parts simultaneous (max.), Preset: 10,922 types or more, User: 256 types | |
| Patterns | 128 patterns | 128 patterns | 128 patterns | |
| Pattern tracks | 16 Sequence tracks | 16 Sequence tracks | 16 Sequence tracks | |
| Pattern Recording type | Real time replace, Real time overdub | Real time replace, Real time overdub | Real time replace, Real time overdub | |
| Songs | 128 songs | 128 songs | 128 songs | |
| Song tracks | 16 Sequence tracks, Tempo track, Scene track | 16 Sequence tracks, Tempo track, Scene track | 16 Sequence tracks, Tempo track, Scene track | |
| Song recording type | Real time replace, Real time overdub, Real time punch in/out | Real time replace, Real time overdub, Real time punch in/out | Real time replace, Real time overdub, Real time punch in/out | |
| USB audio interface | [Sampling Frequency = 44.1 kHz] Input: 4 channels (2 stereo channels), Output: 10 channels (5 stereo channels) [Sampling Frequency = 44.1kHz / 48kHz / 96kHz] Input: 2 channels (1 stereo channel), Output: 2 channels (1 stereo channel) | [Sampling Frequency = 44.1 kHz] Input: 4 channels (2 stereo channels), Output: 10 channels (5 stereo channels) [Sampling Frequency = 44.1kHz / 48kHz / 96kHz] Input: 2 channels (1 stereo channel), Output: 2 channels (1 stereo channel) | [Sampling Frequency = 44.1 kHz] Input: 4 channels (2 stereo channels), Output: 10 channels (5 stereo channels) [Sampling Frequency = 44.1kHz / 48kHz / 96kHz] Input: 2 channels (1 stereo channel), Output: 2 channels (1 stereo channel) | |
| Controllers | Master Volume, A/D Input Gain knob, Pitch Bend wheel, Modulation wheel, Control Slider x 8, Knob x 4, Super knob, Display knob x 6, Portament knob, Data Dial, Assignable swich x 2, MSEQ trigger switch, Portamento switch, Keyboard hold switch | Master Volume, A/D Input Gain knob, Pitch Bend wheel, Modulation wheel, Control Slider x 8, Knob x 4, Super knob, Display knob x 6, Portament knob, Data Dial, Assignable swich x 2, MSEQ trigger switch, Portamento switch, Keyboard hold switch | Master Volume, A/D Input Gain knob, Pitch Bend wheel, Modulation wheel, Control Slider x 8, Knob x 4, Super knob, Display knob x 6, Portament knob, Data Dial, Assignable swich x 2, MSEQ trigger switch, Portamento switch, Keyboard hold switch | |
| Display | 7″ TFT Color Wide VGA LCD touch screen | 7″ TFT Color Wide VGA LCD touch screen | 7″ TFT Color Wide VGA LCD touch screen | |
| Connectors | USB [TO DEVICE], USB [TO HOST], MIDI [IN]/[OUT], FOOT CONTROLLER [1]/[2], FOOT SWITCH [SUSTAIN]/[ASSIGNABLE], OUTPUT [L/MONO]/[R] (6.3 mm, standard phone jacks), [PHONES] (6.3 mm, standard stereo phone jack), A/D INPUT [L/MONO]/[R] (6.3 mm, standard phone jacks) | USB [TO DEVICE], USB [TO HOST], MIDI [IN]/[OUT], FOOT CONTROLLER [1]/[2], FOOT SWITCH [SUSTAIN]/[ASSIGNABLE], OUTPUT [L/MONO]/[R] (6.3 mm, standard phone jacks), [PHONES] (6.3 mm, standard stereo phone jack), A/D INPUT [L/MONO]/[R] (6.3 mm, standard phone jacks) | USB [TO DEVICE], USB [TO HOST], MIDI [IN]/[OUT], FOOT CONTROLLER [1]/[2], FOOT SWITCH [SUSTAIN]/[ASSIGNABLE], OUTPUT [L/MONO]/[R] (6.3 mm, standard phone jacks), [PHONES] (6.3 mm, standard stereo phone jack), A/D INPUT [L/MONO]/[R] (6.3 mm, standard phone jacks) | |
| Power Consumption | 19 W (When using PA-300C AC adaptor) | 19 W (When using PA-300C AC adaptor) | 19 W (When using PA-300C AC adaptor) | |
| Accessories | AC adaptor: PA-300C, Quick guide, Cubase AI Download Information, Expanded Softsynth Plugin for MONTAGE M/MODX M Download Information, About downloading manuals, Welcome card | AC adaptor: PA-300C, Quick guide, Cubase AI Download Information, Expanded Softsynth Plugin for MONTAGE M/MODX M Download Information, About downloading manuals, Welcome card | AC adaptor: PA-300C, Quick guide, Cubase AI Download Information, Expanded Softsynth Plugin for MONTAGE M/MODX M Download Information, About downloading manuals, Welcome card | |
| Live Sets | Preset: 256, User: 2,048 | Preset: 256, User: 2,048 | Preset: 256, User: 2,048 | |
Seda toodet müüakse Yamaha Music Europe nimel ning kohaldatakse Yamaha üldtingimusi ja andmekaitseteavet.
Yamaha üldtingimused ja Yamaha andmekaitseteabe leiate aadressilt: http://bit.ly/conditions-UK ja http://bit.ly/data-protect-EN
| Weight | 7.6 kg |
|---|---|
| Tootja: |
